Blue Sea Systems 5-Circuit 12V Distribution Panel – Dual USB + 12V Socket (Model 8120)

Description

8120 – 5 Position 12V Panel w/Dual USB & 12V Socket

Part of the Blue Sea Systems Battery Management Panels.  Distribute current from a high amperage source to lower amperage circuits.

Features:

• ON-indicating LEDs
  • Backlit label positions
• All positive, negative, and grounding buses installed, fully pre-wired

Specifications:

• Positions – Five (5)
• Nominal Voltage – 12V DC
• Maximum Amperage – 50A
• Circuit Breaker Type – Magnetic Hydraulic – Trip Free
• USB Output – 12/24V Dual USB
• Socket Output – 12V Dash socket
• Dimensions (H x W x D) – 7.5″ x 5.25″ x 2.5″ (191 x 133 x 64mm)

In the Box:

• 8120 Panel
• Instruction Manual

*Sold as an Individual

Specifications:

• AC/DC: DC
• Max Breaker Quantity: 5
• Voltage: 12
• Box Dimensions: 5″H x 7″W x 12″L WT: 1.95 lbs
• UPC: 632085081201

Owner’s Manual (pdf)
