Uflex Power A Single-Engine, Single-Station Hybrid Control Package (Electronic Throttle, Mechanical Shift) [EM11]

Description

Power A EM11 – Electronic Control Package

Power A Mark II™ Electronics Control Systems

• Private Protocol can bus for data transmission
• Connection of multiple stations up to 4 controls
• Modular System
• Direct communication w/electronic engines (SAE J 1939 or NMEA 2000)
• Plug’N Play connectivity
• Automatic engines synchronization
• Dock Assist
• Fully programmable shift delays

EM11 Package Includes:

• 42009G – (1) PA2-B1 – Single Lever Control w/o Trim
• 42017F – (1) PA2-CU – Control Unit w/LED Diagnostic & Programming Screen
• 42018H – (1) PA2-VT – V-Throttle f/0-5V Interface
• 42027J – (1) PA2-MA – Electro-Mechanical Actuator f/Shift and/or Throttle
• 42028L – (1) PA2-NT – Network Terminator
• 42029N – (1) T-VT2 – Universal V-Throttle Cable 6.5′
• 42053K – (1) M-P3 – Main Power Supply Cable, 9.8′
• 71021K – (1) CAN-10 – Network Connection Cable 33′
• 73639T – (2) CAN-1 – Network Connection Cable 3′

Quick Guide (pdf)
Brochure (pdf).embed-container { position: relative; padding-bottom: 56.25%; height: 0; overflow: hidden; max-width: 100%; } .embed-container iframe, .embed-container object, .embed-container embed { position: absolute; top: 0; left: 0; width: 100%; height: 100%; }
